Specification
| Volt | 12V |
| Power | 1.4KW |
| Teeth | 9T |
| Rotation | CW |
OE NO
| BOSCH | 0001108088 |
Ref No
| VOLVO | 1357199 |
| Lester | 17135 |
| LUCAS | LRS02136 |
| HC PARTS | CS389 |
Adapted models
| VOLVO | 240 2.0L [B19ET] 1982-1984 |
| VOLVO | 940 2.3L [B230FB] 1990-1994 |
| VOLVO | 740 2.0L [B200E] 1985-1991 |
Components
Mounting type
| Mount Hole Dia | M12, M12 |
| Flange Dia | 82.2mm |
| Mount Holes Cnt to Cnt | 105.5mm |
| Pinion Dia | 25mm |
| Out of Mesh Clearance | 35.5mm |
| Overall Length | 242.5mm |
| HSG Length | 168.5mm |
| Rest Position B | 140mm |
| S terminal size | 6.35*0.8 |
| B+ terminal size | M8 |
| WEIGHT KG |
