Specification
| Volt | 12V |
| Power | 1.0KW |
| Teeth | 10T |
| Rotation | CCW |
OE NO
| BOSCH | 0001121412 |
Ref No
| BOSCH | 0001121413 |
| VW | 02E911023J |
| Lester | 19001 |
| LUCAS | LRS02220 |
Adapted models
| AUDI | A3 2.0 TFSi [AXX] 2004-2012 |
| AUDI | TT 2.0 TFSi [BPY] 2006-2010 |
| SEAT | Leon 2.0 TFSi [BWA1] 2005-2006 |
| SKODA | Octavia 2.0 RS [BWA] 2005-2013 |
| VW | Eos 2.0 TFSi [BPY] 2006-2015 |
| VW | Golf V 2.0 [CCTA] 2007-2009 |
Components
Mounting type
| Mount Hole Dia | 11mm,11mm |
| Flange Dia | 76mm |
| Mount Holes Cnt to Cnt | 119mm |
| Pinion Dia | 27.5mm |
| Out of Mesh Clearance | 42.5mm |
| Overall Length | 214mm |
| HSG Length | 165mm |
| Rest Position B | 168mm |
| S terminal size | |
| B+ terminal size | M8 |
| WEIGHT KG |
