Specification
| Volt | 12V |
| Power | 2.0KW |
| Teeth | 11T |
| Rotation | CW |
OE NO
| DENSO | 428000-9470 |
Ref No
| IVECO | 5801422464 |
| LUCAS | LRS04097 |
Adapted models
| IVECO | Daily 29L13 2.3D[F1AE3481B] 2011-14 |
| IVECO | Daily 33S11 2.3D[F1AFL411A] 2014-21 |
Components
Mounting type
| Mount Hole Dia | M8, M8, M8 |
| Flange Dia | 84mm |
| Mount Holes Cnt to Cnt | 121*94*70mm |
| Pinion Dia | 42mm |
| Out of Mesh Clearance | 27mm |
| Overall Length | 246mm |
| HSG Length | 180mm |
| Rest Position B | 144mm |
| S terminal size | M6 |
| B+ terminal size | M8 |
| WEIGHT KG | 4.25Kg |
