Specification
| Volt | 12V |
| Power | 2.5KW |
| Teeth | 11T |
| Rotation | CW |
OE NO
| DELCO | 8000455 |
Ref No
| HYUNDAI | 36100-4A100 |
| MITSBUSHI | LRS02784 |
Adapted models
| HYUNDAI | H-1 2.5 CRDi [D4CB] 2008- |
| KIA | K2500 2.5 CRDi [D4CB] 2010- |
Components
Mounting type
| Mount Hole Dia | M10, M10 |
| Flange Dia | 78.5mm |
| Mount Holes Cnt to Cnt | 106.5mm |
| Pinion Dia | 35mm |
| Out of Mesh Clearance | 18mm |
| Overall Length | 220mm |
| HSG Length | 163mm |
| Rest Position B | 143mm |
| S terminal size | |
| B+ terminal size | M8 |
| WEIGHT KG | 3.8Kg |
