Specification
| Volt | 12V |
| Power | 2.2KW |
| Teeth | 10T |
| Rotation | CW |
OE NO
| MITSUBISHI | M2T87271 |
Ref No
| MAZDA | WL02-18-400A |
| LESTER | 32352 |
| LUCAS | LRS02160 |
Adapted models
| FORD | Ranger 2.5D WL 1999-02 |
| MAZDA | B 2500 2.5D MD25NA 1999-06 |
Components
Mounting type
| Mount Hole Dia | M10, M10, M10 |
| Flange Dia | 81.5mm |
| Mount Holes Cnt to Cnt | 75*95*137mm |
| Pinion Dia | 32mm |
| Out of Mesh Clearance | 16.5mm |
| Overall Length | 227mm |
| HSG Length | 174mm |
| Rest Position B | 127mm |
| S terminal size | |
| B+ terminal size | M8 |
| WEIGHT KG |
