Specification
| Volt | 12V |
| Power | 1.4KW |
| Teeth | 12T |
| Rotation | CW |
OE NO
| MOTORCRAFT | SA-974 |
Ref No
| FORD | 9L34-11000-AB |
| LESTER | 6646 |
Adapted models
| FORD | F-150 4.6L 1998-02 |
| FORD | F-150 5.4L 2000-02 |
Components
Mounting type
| Mount Hole Dia | 9mm, 9mm, 8.5mm |
| Flange Dia | 76mm |
| Mount Holes Cnt to Cnt | 64.5*62.5*101mm |
| Pinion Dia | 32mm |
| Out of Mesh Clearance | 14mm |
| Overall Length | 218.5mm |
| HSG Length | 197mm |
| Rest Position B | 162mm |
| S terminal size | M6 |
| B+ terminal size | M8 |
| WEIGHT KG | 3.7Kg |
