Specification
| Volt | 12V |
| Power | 0.9KW |
| Teeth | 9T |
| Rotation | CW |
OE NO
| HITACHI | S114-655 |
Ref No
| YANMAR | 119631-77011 |
| LESTER | 19751 |
| LUCAS | LRS01573 |
Adapted models
| YANMAR Engine 2TN66E 1991-05 | |
| YANMAR Engine 3TNA72 1991-05 |
Components
Mounting type
| Mount Hole Dia | 13mm,13mm |
| Flange Dia | 95mm |
| Mount Holes Cnt to Cnt | 110mm |
| Pinion Dia | 29mm |
| Out of Mesh Clearance | 20.5mm |
| Overall Length | 189mm |
| HSG Length | 137mm |
| Rest Position B | 108mm |
| S terminal size | |
| B+ terminal size | M8 |
| WEIGHT KG | 3.6Kg |
