Specification
| Volt | 24V |
| Power | 5.5KW |
| Teeth | 10T |
| Rotation | CW |
OE NO
| Denso | 128000-5730 |
Ref No
| CATERPILLAR | 3E5381 |
| LESTER | 17616 |
| LUCAS | LRS01900 |
Adapted models
| CATERPILLAR 3114 Engine 1991-93 | |
| CATERPILLAR 3116 Engine 1991-93 |
Components
Mounting type
| Mount Hole Dia | 11.5mm, 11.5mm, 11.5mm |
| Flange Dia | 88.6mm |
| Mount Holes Cnt to Cnt | 126.5*79.5*79.5mm |
| Pinion Dia | 40mm |
| Out of Mesh Clearance | 47mm |
| Overall Length | 320mm |
| HSG Length | 242mm |
| Rest Position B | 185mm |
| S terminal size | M5 |
| B+ terminal size | M10 |
| WEIGHT KG | 10Kg |
