Specification
| Volt | 12V |
| Power | 0.8KW |
| Teeth | 9T |
| Rotation | CCW |
OE NO
| Denso | 428000-3130 |
Ref No
| JOHN DEERE | AM134946 |
| KAWASAKI | 21163-7020 |
| LESTER | 18533 |
Adapted models
| JOHN DEERE Utility Vehicle (UTV) Gator TX Kawasaki 15.5HP | |
| KAWASAKI Utility Vehicle (UTV) KAF400 Mule 600 2005-16 |
Components
Mounting type
| Mount Hole Dia | 8.5mm,8.5mm |
| Flange Dia | 62mm |
| Mount Holes Cnt to Cnt | 68mm |
| Pinion Dia | 29mm |
| Out of Mesh Clearance | 8.5mm |
| Overall Length | 205mm |
| HSG Length | 155m |
| Rest Position B | 151mm |
| S terminal size | |
| B+ terminal size | M8 |
| WEIGHT KG |
