Specification
| Volt | 12V |
| Power | 2.3KW |
| Teeth | 9T |
| Rotation | CW |
OE NO
| HITACHI | S13-204 |
Ref No
| YANMAR | 129900-77010 |
| LESTER | 18491 |
| LUCAS | LRS01565 |
Adapted models
| YANMAR SE50-3 4TNE94 1992-98 | |
| KOMATSU WA70A-1 4D98E 1992-98 |
Components
Mounting type
| Mount Hole Dia | 13.5mm,13.5mm |
| Flange Dia | 95mm |
| Mount Holes Cnt to Cnt | 120mm |
| Pinion Dia | 35.5mm |
| Out of Mesh Clearance | 20.5mm |
| Overall Length | 229mm |
| HSG Length | 207mm |
| Rest Position B | 191mm |
| S terminal size | |
| B+ terminal size | M8 |
| WEIGHT KG | 5.35Kg |
