Specification
| Volt | 12V |
| Power | 0.9KW |
| Teeth | 9T |
| Rotation | CCW |
OE NO
| VALEO | D7E52 |
Ref No
| FIAT | 46813058 |
| LESTER | 32726 |
| LUCAS | LRS01726 |
Adapted models
| FIAT | Idea 1.4L 192B2000 2003-10 |
| FIAT | Panda 1.2L 169A4000 2012-18 |
| LANCIA | Ypsilon 1.2L 169A4000 2010-- |
Components
Mounting type
| Mount Hole Dia | M8, 9mm, 8.5mm |
| Flange Dia | 63mm |
| Mount Holes Cnt to Cnt | 108mm |
| Pinion Dia | 25mm |
| Out of Mesh Clearance | 10.5mm |
| Overall Length | 182mm |
| HSG Length | 128mm |
| Rest Position B | 138mm |
| S terminal size | |
| B+ terminal size | M8 |
| WEIGHT KG | 3.1Kg |
