Specification
| Volt | 12V |
| Power | 1.2KW |
| Teeth | 9T |
| Rotation | CW |
OE NO
| HITACHI | S114-832 |
Ref No
Adapted models
| ISUZU Engine 4ZE1 |
Components
Mounting type
| Mount Hole Dia | 11mm, 11mm |
| Flange Dia | 88.8mm |
| Mount Holes Cnt to Cnt | 127mm |
| Pinion Dia | 29mm |
| Out of Mesh Clearance | 23mm |
| Overall Length | 186mm |
| HSG Length | 160mm |
| Rest Position B | 136mm |
| S terminal size | |
| B+ terminal size | M8 |
| WEIGHT KG |
