Specification
| Volt | 12V |
| Power | 1.8KW |
| Teeth | 9T |
| Rotation | CW |
OE NO
| MITSUBISHI | M1T81582 |
Ref No
| MAZDA | SH1B-18-400 |
| LESTER | 30565 |
| LUCAS | LRS03921 |
Adapted models
| MAZDA | 3 2.2D SHY4 (BM4) 2013-19 |
| MAZDA | 6 2.2D SHY4 (GJ2) 2013-20 |
| MAZDA | CX5 2.2D SHY8 (KFGW) 2018-- |
Components
Mounting type
| Mount Hole Dia | M12, 13mm, 13mm |
| Flange Dia | 73mm |
| Mount Holes Cnt to Cnt | 134*62.5*98mm |
| Pinion Dia | 29mm |
| Out of Mesh Clearance | 2.0mm |
| Overall Length | 221mm |
| HSG Length | 183mm |
| Rest Position B | 139mm |
| S terminal size | |
| B+ terminal size | M8 |
| WEIGHT KG | 3.7Kg |
