Specification
| Volt | 12V |
| Power | 1.0KW |
| Teeth | 8T |
| Rotation | CW |
OE NO
| MITSUBISHI | M0T33071 |
Ref No
| SUZUKI | 31100-M68K10 |
| NISSAN | 23300-4A00B |
| MITSUBISHI | M0T33071ZM |
| LESTER | 31245 |
| LUCAS | LRS02503 |
Adapted models
| NISSAN | Pixo 1.0L K10B 2009- |
| SUZUKI | Alto 1.0L K10B 2009- |
Components
Mounting type
| Mount Hole Dia | 11.5mm, M10 |
| Flange Dia | 70mm |
| Mount Holes Cnt to Cnt | 101.5mm |
| Pinion Dia | 28mm |
| Out of Mesh Clearance | 27.5mm |
| Overall Length | 173mm |
| HSG Length | 114mm |
| Rest Position B | 106mm |
| S terminal size | |
| B+ terminal size | M8 |
| WEIGHT KG | 2.4Kg |
