Specification
| Volt | 24V |
| Power | 5.5KW |
| Teeth | 12T |
| Rotation | CW |
OE NO
| MITSUBISHI | M9T62871 |
Ref No
| DEUTZ | 0118-2495 |
| KHD | 118-2760 |
| VOLVO | 20900793 |
| LESTER | 19106 |
| LUCAS | LRS02607 |
Adapted models
| DEUTZ | Engine TCD 2012- |
| VOLVO | L60F 2008-- |
Components
Mounting type
| Mount Hole Dia | 11.5mm, 11.5mm, 11.5mm |
| Flange Dia | 88.8mm |
| Mount Holes Cnt to Cnt | 126.5mm |
| Pinion Dia | 43.8mm |
| Out of Mesh Clearance | 46mm |
| Overall Length | 318mm |
| HSG Length | 264.5mm |
| Rest Position B | 229mm |
| S terminal size | M5 |
| B+ terminal size | M10 |
| WEIGHT KG | 8.9Kg |
